Focal Trio6

SKU: ARM-MON-FOC-FOCTRIO6ST6BLK

Focal Trio6 ST6 — Three-Way Studio Monitor

Trio6 combines dedicated bass, midrange and treble drivers with two alternative Focus configurations. Switch between the full three-way system, midrange-and-tweeter monitoring and a midrange-only reference to assess balance and translation from the same listening position.

Key features

  • 8-inch W-cone bass driver and 5-inch W-cone midrange
  • 1-inch inverted-dome beryllium tweeter
  • Dual Focus modes
  • Balanced XLR input
  • High-pass filter and rear-panel EQ
  • Select Red or Black before ordering

Sold individually

Price is for one monitor in the selected colour. Order two for a stereo pair.

Price $6,599.00 AUD

Including GSTinc. · per speaker

In stock

Collection or delivery by arrangement

Please contact ARM before ordering speakers. We’ll confirm availability and discuss collection, local delivery or a freight quote before you pay.

Email ARM about this speaker
Enquire about collection or delivery

Please contact ARM before ordering speakers. We’ll confirm availability and discuss collection, local delivery or a freight quote before you pay.

Contact ARM to confirm stock availability and your required configuration.

TECHNICAL DETAILS

Specifications

The details you need to plan your system. Expand a section to explore.

Dimensions & weight
Dimensions & weight
SpecificationDetails
Height53.7 cm
Width29.2 cm
Depth36.9 cm
Weight25 kg
Acoustic performance
Acoustic performance
SpecificationDetails
Product type3-way monitor
LoudspeakersSubwoofer : 8" W membrane; Woofer : 5" W membrane; Tweeter : 1" Beryllium inverted dome
Frequency response (±3 dB)3-way mode: 35 Hz - 40 kHz; 2-way mode (Focus): 80 Hz - 20 kHz; 1-way mode (Focus): 100 Hz - 15 kHz
Maximum SPL (Focal web table, 1 m)115 dB
Connections, amplification & controls
Connections, amplification & controls
SpecificationDetails
Bass/midrange level (160 Hz)Adjustable, +/-3 dB
InputsXLR: balanced 10 kΩ
High-pass filterFull range, 45 Hz, 60 Hz, 90 Hz
LEDPower on; Focus mode; Clipping, default and stand-by
Mains supply100–120 V AC or 220–240 V AC
High frequency amplifier50 W, class AB
Low-frequency shelvingAdjustable, +/-3 dB
Power switchOn/Off switch on the rear panel
Mid-range and low frequency amplifierBass : 100 W, class G • Midrange : 100 W, class G
High-frequency shelvingAdjustable +/-3dB
Indicators and controlsSensitivity; Auto standby; HPF, LF Shelv, LMF EQ, HF Shelv; Focus Mode
Cabinet & operating environment
Cabinet & operating environment
SpecificationDetails
ShieldingNot magnetically shielded
Cabinet22 mm MDF
Operating temperature5–35°C
Storage temperature0–50°C
Mains frequency50/60 Hz
Focus performance
Focus performance
SpecificationDetails
Focus maximum SPL112 dB in either Focus mode; average CEA2034, 100 Hz–10 kHz, free field at 1 m

Focal’s web table lists Focus 2 response as 80 Hz–20 kHz and a 1-inch tweeter; the linked product sheet lists 80 Hz–40 kHz and a 1.5-inch tweeter. Web-table values are retained above; differing sheet values are identified here for confirmation.

Technical specifications: Focal product page and product sheet. Reformatted for ARM.
